Blackmagic Micro Studio Camera 4K G2 – New release – Brand new

The Blackmagic Micro Studio Camera 4K G2 is an amazing live production camera in a tiny body for broadcast quality. The Four-Thirds sensor delivers 13 stops of dynamic range, incredible low-light performance and stunning Ultra HD images in all lighting conditions. Micro BNC connectors for 12G-SDI support uncompressed 10-bit video up to 2160p/60 and can output 2-channel audio. Tally, camera control, control of the integrated colour corrector and lens control via an ATEM mixer are supported at the input. If an ATEM Mini Mixer is in use, the HDMI port outputs 1080 signals and supports all control functions. And since the camera can record Blackmagic RAW to external USB-C storage, it is a film camera for Hollywood quality. Thanks to multiple mounting points, the Blackmagic Micro Studio Camera 4K G2 can easily be placed where other cameras are too bulky.

Camera-Features

• Effective sensor size: 17.78 mm x 10 mm (Four Thirds)
• Lens mount: MFT bayonet with electronic aperture control
• Aperture control: Aperture, focus, zoom with supported lenses
• Dynamic range: 13 f-stops
• Dual native ISO: 0 dB and 18 dB gain
• Sensitivity at 0 dB gain:
• f11 at 2160p/59
• f12 at 2160p/50
• 2000 lux at 89.9 % reflection
• Signal-to-noise ratio: 63 dB at 2160p
• Resolutions for filming: 3840 x 2160 (Ultra HD) up to 60 fps
• Frame rates: 23.98; 24; 25; 29.97; 30; 50; 59.94; and 60 frames per second.
• Offspeed frame rates of up to 60 fps in Ultra HD
• Focusing: Autofocus available when using compatible lenses
• Mounting options:
• 1x 1/4-inch thread (top)
• 3 x 1/4-inch thread (bottom)
• Connections
• SDI video inputs: 1
• SDI video outputs: 1
• SDI rates: 3G; 6G; 12G.
• HDMI 2.0 video outputs: 1
• HDMI video outputs: 1 HDMI type A output
• HDMI output is always in HD at frame rates up to 1080p/60
• Analogue audio inputs: 1x 3.5mm stereo input. Can also be used as timecode input
• Reference inputs: Programme SDI input to camera or Blackmagic Studio Converter
• SDI audio outputs: 2 channels of programme audio embedded in 3G/6G/12G-SDI
• HDMI audio outputs: 2 channels 48 kHz and 24 bit
• Remote control: Remote control of the camera via SDI, HDMI or USB Ethernet with suitable adapter
• Computer interface: 1 USB-C 3.1 Gen 1 (up to 5 Gbit/s) expansion port for connection to external recording devices and Focus and Zoom Demand devices. USB-C port for software updates.

Connections

SDI video inputs: 1

SDI video outputs: 1

SDI rates: 3G; 6G; 12G.

HDMI 2.0 video outputs: 1

HDMI video outputs: 1 HDMI type A output

HDMI output is always in HD at frame rates up to 1080p/60

Analogue audio inputs: 1x 3.5mm stereo input. Can also be used as timecode input

Reference inputs: Programme SDI input to camera or Blackmagic Studio Converter

SDI audio outputs: 2 channels of programme audio embedded in 3G/6G/12G-SDI

HDMI audio outputs: 2 channels 48 kHz and 24 bit

Remote control: Remote control of the camera via SDI, HDMI or USB Ethernet with suitable adapter

Computer interface: 1 USB-C 3.1 Gen 1 (up to 5 Gbit/s) expansion port for connection to external recording devices and Focus and Zoom Demand devices. USB-C port for software updates.

All information without guarantee. Please also refer to the manufacturer’s current and detailed information.

The goods are in their original packaging and will be dispatched with an invoice and VAT shown.

This offer is aimed exclusively at commercial buyers, freelancers and institutions!
