AJA MINI-CONNECT

Control AJA Mini-Converters via Ethernet

The AJA Mini-Connect device enables control of up to 4 USB-enabled AJA Mini-Converters over a single Ethernet connection. Mini-Connect integrates with your existing Ethernet network to provide access using any web browser for easy configuration and control of Mini-Converters anywhere in your facility.

Connect. Control.
Mini-Connect extends control of your ROI Mini-Converters across the local network or across the web for access anywhere!

Now it’s possible to configure and set parameters for your ROI Mini-Converters remotely using any web browser on any platform through Mini-Connect, allowing quick and efficient parameter changes, whenever the need arises.

Install Mini-Connect and attach up to four AJA ROI Mini-Converters via USB, then configure and control them from anywhere, anytime across Mini-Connect’s fast and reliable Ethernet connection.

Mini-Connect’s embedded web server means there is no software to install, simply open a web browser on any OS and gain full access to your ROIs from your desk, or anywhere in the world.

Key Features:
Supported AJA Mini-Converters

• ROI
• ROI-DVI
• ROI-HDMI
• ROI-DP
• Future updates will include support for additional
AJA Mini-Converters

Network Interface

• 10/100/1000 Ethernet (RJ-45)
• Embedded webserver for remote control
• Configuration and transport control via web browser
interface

USB Configuration

• Configuration and device control of up to four
ROI Mini-Converters via web browser based UI

AJA eMini Setup
AJA eMini Setup software allows quick and easy network setting configuration and device updates for AJA’s Ethernet equipped Mini-Converters. Simply connect your computer to the same network as the Mini-Connect and open the free AJA eMini Setup software to discover your Mini-Connect on the network for further configuration.

Universalnetzteil
Alle AJA Mini-Converter werden mit einem Universalnetzteil geliefert, das durch die internationalen Steckvorrichtungen auf der ganzen Welt eingesetzt werden kann.

Kompakt und tragbar
Die AJA Mini-Converter passen dank ihrer geringen Größe hinter den Monitor oder können hinten an einem Rack oder direkt an einen Kameraträger angebracht werden. Der verriegelbare Netzstecker kann nicht versehentlich abgezogen werden. Mit dem optionalen P-TAP-Netzkabel ist die Stromversorgung an abgelegenen Orten auch über Batterie möglich.

AJA-Qualität − garantiert
Auf alle AJA Mini-Converter wird eine Garantie von 5 Jahren gewährt. Sie unterliegen zudem der erweiterten Austauschrichtlinie. Ist ein Austausch erforderlich, liefert AJA sofort ein neues Gerät, ohne dass das Originalgerät zuerst zurückgesendet werden muss, um sicherzustellen, dass Sie so schnell wie möglich Ihre Arbeit wieder aufnehmen können.

AJA Mini-Matrix
Informationen über die komplette Mini-Converter-Produktreihe von AJA sind jetzt als App für Mobile-iOS erhältlich. Die Mini-Converter-Produktreihe ist sehr umfangreich. Mit Hilfe dieser App können Sie an jedem beliebigen Ort den für Sie idealen Converter wählen.

Einzelne Produkte enthalten Links zur Hauptseite von AJA für weitere Details, und Sie können Informationen über das Produkt per E-Mail erhalten. Die kostenlose AJA Mini Matrix-App für iPad und iPhone ist ab sofort im Apple iTunes Store erhältlich.

Tech Specs

Supported AJA Mini-Converters
• ROI
• ROI-DVI
• ROI-HDMI
• ROI-DP
• Others TBD*
*NOTE: Future Software Release

Network Interface
• 10/100/1000 Ethernet (RJ-45)
• Embedded webserver for remote control via Mini-Connect
• Configuration and Transport Control via WEB Interface

USB Configuration
Configuration and Device Control via Web based UI

USB (interface with ROI converters)
Connect up to 4 ROI Mini-Converters for control via ethernet

User Interface
Web Based UI running Mini-Connect software

Physical
• Width: 4.6” (109mm)
• Depth: 2.4” (78mm)
• Height: 1” (25mm)
• Power: Uses AJA Power Supply model DWP-U-R1 (included with purchase)
• 100-240V, 50/60Hz Universal Input
• +5 to 20V DC regulated, 8 watts max


Die Ware ist
original verpackt und wird mit Rechnung und ausgewiesener
Mehrwertsteuer versendet.
Diese Hardware ist Umtausch- und
Rückgaberecht ausgeschlossen. Dieses Angebot richtet sich ausschließlich an gewerbliche Käufer.

Zusätzliche Information

Marke

AJA

Produktart

Konverter

Herstellernummer

MINI-CONNECT

ConditionNew
×
