AJA FS1-X Universal Frame Synchronizer/Converter

4.849,90 €

inkl. MwSt. zzgl. Versandkosten

Lieferzeit: 10 Werktage

FS1-X
Spektakuläre Frame Rate Konvertierung

Das Schweizer Taschenmesser unter den Konvertern jetzt auch mit Frame-Rate Konversion
• Frame-Rate Konversion von PAL nach NTSC
• 64 Kanal optischer und koaxialler MADI I/O für Audio
• SDI, HDMI und Fiber(optional) Video I/O
• 5 Jahre Garantie mit advanced Replacement

AJA´s FS1-X markiert die nächste Entwicklungsstufe bei der Frame Rate Synchronisierung und Konvertierung. Auf Grundlage der starken AJA Konvertierungstechnologie wird der FS1-X zum Schlüssel für die Harmonisierung verschiedener Video Standards und zum Management Tool für die stetig wachsende Zahl von Audio Kanälen und Formaten.

Werden Sie International
Mit der vorinstallierten Frame Rate Converter (FRC) Option führt der FS1-X für Sie hochqualitative Konvertierungen zwischen verschiedenen Frame Rates durch und unterstützt dabei nahezu alle internationalen Standards.

Unerreichte Audio Flexibilität
Der FS1-X unterstützt 64-Kanal MADI Ein- und Ausgänge über optische und koaxial Kabel.Eine interne 224 x 224 Audio Matrix erlaubt das Routing von MADI Signalen und dem Audio aus SDI, Fiber, AES und analogen Quellen. Damit steht Ihnen unerreichte Audio Processing Power aus einem einzelnen Gerät zur Verfügung.

Automation
Der FS1-X ist für eine einfache Integration in Ihre existierende Infrastruktur gemacht. Viele Funktionen wie z.B. das Freezen eines Eingangs oder die Umschaltung zwischen verschiedenen Presets können von externen GPI´s gesteuert werden. Ein integrierter Webserver erlaubt die Konfiguration und Automation durch den Webbrowser einer beliebigen Plattform.

—————————-

FS1-X
Integrate the world

FS1-X is the next evolution in frame synchronization and conversion. Within its compact 1RU chassis, FS1-X integrates an amazing array of video and audio connectivity and processing, including 56- and 64-channel MADI audio over coax or fiber. With its flexible architecture, FS1-X utilizes a high-quality, motion adaptive linear Frame Rate Converter for smooth motion conversion between a wide range of frame rates whether for broadcast, production or live events.

Incredible frame rate conversion option*
Matching up and synchronizing disparate video and audio formats is a critical part of any broadcast, mobile or post-production environment. With the factory-installed motion adaptive Frame Rate Converter (FRC) option, FS1-X creates incredible, high-quality conversions between different frame rate families for virtually unlimited international standards support.

*Optional. Factory installation required at time of order. (»ComLine Artikelnummer: VZ-305961033)

Massive audio flexibility
The growth of 5.1 and 7.1 audio has increased the number of audio channels that must be managed in a production as well as needing to create stereo mixdowns from 5.1 and 7.1 sources. The MADI standard provides a convenient way to transport huge numbers of audio channels along a single cable, simplifying the cabling demands for broadcasters, mobile trucks and production. FS1-X supports both fiber and coax 56- and 64-channel MADI input and output. An internal 224×224 audio matrix allows full routing of MADI, mixdowns and all audio coming from SDI, fiber, AES and analog sources for an incredible amount of audio processing capability in a single box.

High-quality conversion
AJA’s hardware conversion technology ensures the highest image quality for your productions.

Key conversion features include:
• SD/HD up, down-conversion
• SD/SD aspect ratio conversion
• HD/HD cross-conversion (720p/1080i)
• Up, down, cross-conversion with both the input and converted formats on SD/HD SDI outputs (both synchronized)
• HD cross-conversion with simultaneous down-converted SDI output
• Automatic Reverse Telecine detection and removal
• Closed Caption conversion (CEA-608/CEA-708 standards)
• AFD conversion or pass-through (user-selectable)

Sidebar Keying
FS1-X features a unique keyer configuration, allowing incoming signals to be combined in powerful ways. A common example is sidebar keying, where incoming video is converted from SD to HD but rather than stretching the 4:3 aspect ratio to fit in a 16:9 frame, a second signal is used to fill the sides of the 16:9 frame. This allows channel identification or other imagery to be placed in that area rather than having black bars on either side. The robust AFD features of FS1-X ensure that the aspect ratio of the outgoing signal is properly identified for downstream devices.

Automation
Many functions on FS1-X can be triggered by external GPI’s such as freezing an input or switching between presets, allowing easy integration into existing systems for seamless and accurate automation.

Extensive Connectivity
FS1-X is loaded with comprehensive I/O for converting between the widest range of analog and digital signals. Perfect for use in all broadcast and post production environments, featuring 3G-SDI inputs and outputs, HDMI, comprehensive multi-channel audio connections supporting the latest standards, and I/O for analog video equipment, including HD and SD component.

Architecture
FS1-X is designed to maximize flexibility while providing a dependable solution that is engineered to meet the demands of broadcast engineering. Dual, redundant power supplies ensure FS1-X remains online even in the event of a power supply failure.

Tech Specs

Video Input/Output Formats
SDI and Fiber

The FS1-X has two standard SDI video inputs and outputs, and two optional Fiber video inputs and outputs.

 All SDI video inputs and outputs, including Fiber, are YCbCr 4:2:2 pixel format.

 Fiber connections support 3G-SDI, SMPTE-259/292/296, 8- or 10-bits (optional)

  • Single-channel LC connector modules
  • Single-channel SC connector modules
  • Dual-channel LC connector modules

 2.97 Gb 3G-SDI Level B (SMPTE 425-B / SMPTE 372)

  • 2K 1080p 50
  • 1080p 50 (SMPTE 274)

 3G-SDI Level B 2.967 (2.97/1.001) Gb (SMPTE 425-B / SMPTE 372)

  • 2K 1080p 59.94
  • 1080p 59.94 (SMPTE 274)

 3G-SDI Level A 2.97 Gb (SMPTE 425-A)

  • 2K 1080p 50
  • 1080p 50 (SMPTE 274)

 3G-SDI Level A 2.967 (2.97/1.001) Gb (SMPTE 425-A)

  • 2K 1080p 59.94
  • 1080p 59.94 (SMPTE 274)

 Dual-link HD-SDI, 2x 1.485Gb (SMPTE 372)

  • 2K 1080p 50
  • 1080p 50

 Dual-link HD-SDI, 2x 1.4835Gb (SMPTE 372)

  • 2K 1080p 59.94
  • 1080p 59.94

 HD-SDI, 1.4835 Gb (SMPTE 292)

  • 2K 1080p 23.98, 29.97
  • 1080p 23.98, 29.97
  • 1080PsF 23.98, 29.97
  • 1080i 59.94
  • 720p 59.94

 SD-SDI, 270Mb (SMPTE 259-C)

  • 625i 50
  • 525i 59.94
HDMI

The HDMI input only accepts SMPTE video formats, and accepts embedded audio. Video input formats are RGB or YCbCr 4:2:2 pixel format for consumer video scan formats. Computer scan rates are not supported.

  • 1080p 23.98, 24, 25, 29.97, 50, 59.94
  • 1080i 50, 59.94
  • 720p 50, 59.94
  • 625p 50
  • 625i 50
  • 525p 59.94
  • 525i 59.94
Component HD/SD Analog

The Component Analog Input accepts YCbCr 4:2:2 pixel format, configurable to SMPTE or Betacam levels. If the composite input is used, the component input is not available.

  • 1080p 23.98, 24, 25, 29.97
  • 1080PsF 23.98, 24, 25, 29.97
  • 1080i 59.94
  • 720p 50, 59.94
  • 625i 50
  • 525i 59.94
Composite SD Analog

The FS1-X composite analog video input/output formats are listed below. If the component inputs are used, the composite input is not available.

  • 625i 50
  • 525i 59.94 (switchable to NTSC 7.5 IRE or 0 IRE setup)
Reference
  • 1080p 50 tri-level sync
  • 1080i 50, 59.94 tri-level sync
  • 720p 50, 59.94 tri-level sync
  • 525i 59.94, 625i 50 analog composite
  • Genlock available to the current Video Processor 1 Input
  • Free run
Formal Exceptions

 The following formats are not supported:

  • 720p 23.98, 24, 25, 29.97
  • All 30, 60 frame rates
  • 4:4:4 YCbCr, RGB, or XYZ inputs
  • 4:2:2 YCbCr 12-bit inputs
Video Format Conversion
Standard FS1-X Conversions

The standard FS1-X can convert almost any input format to nearly any output format, as long as the frame rates are of the same frame rate family. The three families are:

  • 23.98, 29.97, 59.94
  • 25, 50
  • 24

NOTE: See „Conversion Exceptions“ below

FRC FS1-X Enabled Conversion

When the factory installed Frame Rate Converter (FRC) option is present and active, conversions between different frame rate families are supported. An appropriate genlock reference format will be required.

Supported Conversions, FRC Enabled

Input FormatOutput FormatGenlock Source Formats Supported
525i 59.94625i 50; 1080i 50625i 50; 1080i 50
525i 59.94720p 50; 1080p 25, 50625i 50; 1080i 50; 720p 50
525i 59.941080PsF 25625i 50; 1080i 50
525i 59.942K 1080PsF 25, 50625i 50; 1080i 50; 720p 50
625i 50525i 59.94; 1080i 59.94525i 59.94; 1080i 59.94
625i 50720p 59.94525i 59.94; 1080i 59.94; 720p 59.94
625i 501080PsF 29.97525i 59.94; 1080i 59.94
625i 501080p 29.97, 59.94; 1080PsF 29.97; 2K 1080p 29.97, 59.94525i 59.94; 1080i 59.94; 720p 59.94
1080i 50525i 59.94; 1080i 59.94; 1080PsF 29.97525i 59.94; 1080i 59.94
1080i 50720p 59.94; 1080p 29.97, 59.94; 2K 1080p 29.97, 59.94525i 59.94; 1080i 59.94; 720p 59.94
1080i 59.94625i 50; 1080i 50; 1080PsF 25625i 50; 1080i 50
1080i 59.94720p 50; 1080p 25, 50; 2K 1080p 25, 50625i 50; 1080i 50; 720p 50
720p 501080p 29.97, 59.94; 1080PsF 29.97; 2K 1080p 29.97 59.94525i 59.94; 1080i 59.94; 720p 59.94
720p 50525i 59.94; 1080i 59.94; 1080PsF 29.97525i 59.94; 1080i 59.94
720p 59.94625i 50; 1080i 50; 1080PsF 25625i 50; 1080i 50
720p 59.94720p 50; 1080p 25, 50; 2K 1080p 25, 50625i 50; 1080i 50; 720p 50
1080p 50525i 59.94; 1080i 59.94; 1080PsF 29.97525i 59.94; 1080i 59.94
1080p 501080p 29.97, 59.94; 1080PsF 29.97; 2K 1080p 29.97, 59.94525i 59.94; 1080i 59.94; 720p 59.94
1080p 59.94625i 50; 1080i 50; 1080PsF 25625i 50; 1080i 50
1080p 59.94720p 50; 1080p 25, 50; 2K 1080p 25, 50625i 50; 1080i 50; 720p 50
1080PsF 24625i 50; 1080i 50; 1080PsF 25625i 50; 1080i 50
1080PsF 24720p 50; 1080p 25, 50; 2K 1080p 25, 50625i 50; 1080i 50; 720p 50
1080PsF 24525i 59.94; 1080i 59.94; 1080PsF 29.97525i 59.94; 1080i 59.94
1080PsF 24720p 59.94; 1080p 29.97, 59.94; 2K 1080p 29.97, 59.94525i 59.94; 1080i 59.94; 720p 59.94
1080PsF 23.98625i 50; 1080i 50; 1080PsF 25625i 50; 1080i 50
1080PsF 23.98720p 50; 1080p 25, 50; 2K 1080p 25, 50625i 50; 1080i 50; 720p 50
1080PsF 23.98525i 59.94; 1080i 59.94; 1080PsF 29.97525i 59.94; 1080i 59.94
1080PsF 23.98720p 59.94; 1080p 29.97, 59.94; 2K 1080p 29.97, 59.94525i 59.94; 1080i 59.94; 720p 59.94
Conversion Exceptions

Selecting the following format and frame rate conversions will cause a Video Format alarm.

Non-Supported Conversions

Input FormatOutput Format
525i 59.941080p 23.98; 1080PsF 23.98
1080i 59.941080p 23.98; 1080PsF 23.98
720p 29.97, 59.941080p 23.98; 1080PsF 23.98
1080p 29.97; 1080PsF 29.971080p 23.98; 1080PsF 23.98
625i 501080p 24; 1080PsF 24
1080i 601080p 24; 1080PsF 24
720p 30, 601080p 24; 1080PsF 24
1080p 301080p 24; 1080PsF 24
Video Format Alarms

When incompatible I/O formats are detected, an alarm can be triggered with these results:

  • Lights the relevant alarm LED on the front panel (FMT ERROR, 1 or 2)
  • Displays an alarm in the browser user interface
  • Influences selection of the first-displayed status screen
  • Generates an SNMP trap (if configured)
  • Triggers a GPI Output (if configured)
Video A/D, D/A Converters
  • 12-bits
  • 2 x oversampled (HD)
  • 4 x oversampled (SD)
Audio Inputs/Outputs

The FS1-X can accept and route any audio inputs to any audio output.

  • 8-Channel balanced analog I/O, DB-25F 25-pin connector (Tascam pinout)
  • 16-Channel AES/EBU I/O (BNC), DB-25F 25-pin connector
  • 16-Channel SDI/HD-SDI embedded BNC (2)
  • 16-Channel SDI/HD-SDI embedded Fiber (2)
  • 64-Channels MADI digital audio. BNC
  • 64-Channels MADI digital audio. Fiber
Audio Analog Levels

Analog audio input and output levels, as referenced to full scale digital, can be set to:

+12dBu (consumer), +15dBu, +18dBu, +24dBu (professional)

Audio Adjustments

Individual audio channels (or channel pairs) can adjusted for:

  • Level: +/- 18 dB
  • Phase: Normal or Reverse
  • Delay: -128 to +12288 samples (-2.7 ms to +256 ms)
LAN Interfaces
  • 10/100/1000 automatic configuration
  • Automatic cable crossover (auto MDI-X)
  • Embedded web server
  • SNMP
GPI InteraceDB-15F: Single connector provides four inputs and four outputs. See Appendix B for a connector pinout and GPI specifications
Size (w x d x h)19″ x 16″ x 1.75″ (1RU) (482.6mm x 405.5mm x 44.4mm)
Weight7.9 lbs (3.6 kg)
Power100-240 VAC 50/60 Hz, (Dual, redundant power supplies), 55W typical, 60W with FRC option; 70W max.
Environment
  • Cooled via two internal fans and side vents
  • Safe Operating Temperature: 0 to 40 degrees C (32 to 104 degrees F)
  • Safe Storage Temperature (Power OFF): -40 to 60 degrees C (-40 to 140 degrees F)
  • Operating Relative Humidity: 10-90% noncondensing
  • Operating Altitude: <3,000 meters (<10,000 feet)

Alle Angaben ohne Gewähr. Bitte beachten Sie auch die
aktuellen und detaillierten Informationen des Herstellers.



Die Ware ist original verpackt und wird mit Rechnung und
ausgewiesener Mehrwertsteuer versendet. Diese Hardware ist vom Umtausch- und
Rückgaberecht ausgeschlossen.

Dieses Angebot richtet sich ausschließlich an gewerbliche
Käufer, Freiberufler und Institutionen!

Zusätzliche Information

Herstellernummer

FS1-X

Marke

AJA

Produktart

Synchronizer / Converter

ConditionNew
